首页>>product>>Industrial Vibrating Screen / Slurry screen
Unit integration, diverse configuration
Model number：Customization
yield：15-500 t/h (output varies according to material characteristics)
Use：Liquid materials such as juice, Chinese medicine oral liquid, pulp, ceramic mud, aluminum silver paste, etc.
Because you need it, and we specialize. Welcome to visit the factory！
Consult ustelephone：0373-5701114
Liquid vibrating screen, also known as slurry vibrating screen, is suitable for filtering liquid materials such as juice, Chinese medicine oral liquid, pulp, ceramic slurry, aluminum silver paste, etc. Liquid vibrating screen (slurry screen) has preferential price and complete models.
| Model | Effective screening diameter（mm） | Effective screening area（m²） | Screen specifications (mesh/inch) | Layer number(s) |
| GFGL-600 | Φ560 | 0.23 | 2~500 | 1~2 |
| GFGL-800 | Φ760 | 0.42 | 2~500 | 1~2 |
| GFGL-1000 | Φ930 | 0.64 | 2~500 | 1~2 |
| GFGL-1200 | Φ1130 | 0.95 | 2~500 | 1~2 |
● Suitable for screening machines for filtering various high-mesh and viscous liquids.
● High-frequency mid-flange vibration source, greater force and more uniform transmission.
● Exclusive 360-degree automatic spray head for automatic cleaning.
● Special inlet and outlet gates for more uniform distribution and higher precision.
● Special protection of the vibration source, waterproof, heat-insulated, and long service life.
● Equipped with a liquid level protection device for remote control.
Note: Ranked in no particular order, part.
